APPLICATIONS
- For sewing light to heavy-weight materials including cottons, knits, polyester, nylon, sheer fabrics and denim
- Suitable for stitching such products as blouses, shirts, men's, ladies and children's apparel, uniforms, overalls, lingerie, etc.
- Heavyweight fabrics such as jeans can be sewn by changing the needle plate, feed dog, foot, stitch regulator, hook and needle bar
FEATURES
- Fully automatic lubrication with recirculating high pressure pump
- Noise and vibration absorbing table mounting
- "Feather-touch" pressure foot lifter
- Ultra high speed – 5500 S.P.M.*
- Heavy Bobbin
- Available with roller presser foot
SPECIFICATIONS
Number of Needles 1 (Single) Feeding Mechanism Drop Feed Workspace Standard Workspace Standard or Full Function Standard Functions Speed, Max (S.P.M.) 3500 Speed, Max (S.P.M.) 3000 Clearence Under Presser Foot 1/4" (6mm) Clearence Under Presser Foot 1/4" (6mm) Stitch Length 3 1/2 s.p.i. (7mm) Stitch Length 5 s.p.i. (5mm) Work Space 10" (258mm) Work Space 10" (258mm) Needle 16 x 257 Needle 135 x 5 Bobbin Metal 22T4-017
Pre-wound LBobbin Metal 78T4-005
Pre-wound MBed Size 7" x 18 7/8" (177mm x 477mm) Bed Size 7" x 18 7/8" (177mm x 477mm) Stitch Type 301 Stitch Type 301 Needle Bar Stroke 1 5/16" (33mm) Needle Bar Stroke 1 1/4" (31.8mm) Hook 48T4-001A Hook 22T4-011D
