APPLICATIONS
- For medium to heavy duty materials such as cloth, leather, canvas, vinyls, synthetics and various coated and laminated materials
- Designed for sewing operations which require decorative or functional. angular stitching such as collars, lapels, pocket flaps, pockets and fly fronts
- Used for stitching such products as wearing apparel, table cloths, brassieres and leather accessories
- General parallel / two-needle stitching (top or run stitching)
FEATURES
- The compound feed mechanism assures perfect and uniform stitching and eliminates slippage
- Large hooks and bobbins
- Special bobbin case cap eliminates loose bottom stitches when angular stitching is employed
- Easy operation of disengageable right and left needle bars by use of finger-touch lever
- Centra-Lube® semi-automatic lubrication system
- Automatic hook lubrication
- Oil fed take-up
- Reverse stitching
- Large range of gauge sets available
- Safety clutch protects the hooks from being damaged
SPECIFICATIONS
Number of Needles 2 (Double) Feeding Mechanism Needle Feed Workspace Standard Workspace Standard or Full Function Standard Functions Speed, Max (S.P.M.) 2200 Clearence Under Presser Foot 9/32" (7mm) Stitch Length 4.5 s.p.i. (5.5mm) Work Space 10" (258mm) Needle 135 x 7 Bobbin Pre-Wound U Bed Size 7" x 20 3/8" (177mm x 518mm) Stitch Type 301 Needle Bar Stroke 1 1/4" (32mm) Hook 16407 Needle Distances 1/4" Standard (1/8-1 1/4" avail)
