APPLICATIONS
- Three step/two stitch zig-zag Federal stitch 308
- For sewing elastic and other stretch materials, as well as for ornamental stitching
- For stitching such products as boat and truck covers, tents, awnings sails, parachutes, tarapaulins, canvas bags, also many items of military and naval equipment
- Used on such materials as canvas, nylon, vinyl, leather, synthetics and similar materials
- Especially desierable where reinforced stitch is necessary
- Also available with special fittings for rope tacking operations
- Used for rope tacking, making loops in rope and attaching small and medium size ropes to such products as truck covers, tents, sails, hammocks, parachutes, grain bags and many items of military and naval equipment
FEATURES
- Horizontal axis transverse rotary hook
- Maximum width of zig-zag: 3/8" (9.5mm)
- Straight stitcher when zig-zag is set to 'O' mm
- Long arm with 10" free space between needle and arm (all 18 7/8" bed models)
- Locking zig-zag width regulator
- Reverse stitching
- Special fittings available for rope end and rope loop stitching
- With large bobbin and horizontal axis transverse rotary hook
- Optional: Interchangable between 1A, 2A & 3A stitches; Additional parts required (not included)
ADDITIONAL INFORMATION
SPECIFICATIONS
Number of Needles 1 (Single) Feeding Mechanism Needle Feed Workspace Standard Workspace Standard or Full Function Standard Functions Speed, Max (S.P.M.) Zig-Zag 2000
Straight 2000Clearence Under Presser Foot 15/64" (6mm) Stitch Length 5 s.p.i. (5mm) Work Space 10" (258mm) Needle 135 x 17 Bobbin Metal 212034-312
Pre-wound MBed Size 7 x 18 7/8" (178mm x 480mm) Needle Bar Stroke 1 11/32" (34mm) Hook B-70 Zig-Zag Stitch Width 3/8" (9.5mm)
